Welcome!

All files related to Neurons and BrainBoardz listed here can also be downloaded from our GitHub repository.

Pinouts

Neuron-Z3 and Neuron-M3 Pinouts

The pinout diagram for the
Neuron and Neuron Z3/M3

Download

CircuitPython

The BrainBoardz system currently supports CircuitPython 8. The opensource Mu Editor  (an IDE for CircuitPython) is available for Windows, Mac or Linux operating systems.

Adafruit provides a web interface (Adafruit ESPTool) for uploading CircuitPython firmware.bin files to Neuron modules. Instructions on using Adafuit’s ESP Web Tool are located here.

CircuitPython Downloads

MU Editor (Windows, Mac OSX and Linux Versions)

Download

CircuitPython 8 Official  Library

Download

CircuitPython 8 Unofficial "Community Bundle" Library

CircuitPython 7.X Firmware.bin

for the Neuron (deprecated)

Download

CircuitPython 8.2.5 Firmware.bin for the Neuron (latest version)

CircuitPython (IDE Compiler) Files for CircuitPython 8.2+

CircuitPython Documentation

The CircuitPython organization page

Download

CircuitPython Libraries page. You can download the latest CircuitPython bundle from here

Download

Adafruit's portal for all things related to getting started with CircuitPython

Download

The CircuitPython Version 8
documentation Portal

Download

Arduino

Arduino IDE

Arduino IDE Installers for Windows, Linux and Mac OS X

Download

Arduino configuration for Neurons

MicroPython

We actively support Arduino and CircuitPython, but we have also tested MicroPython and PlatformIO. We can confirm that MicroPython is compatible with the Neuron ESP32S3 module. The ESP32-S3-WROOM-I module on Neuron is the same module as that used on the Espressif developer board ESP32-S3-DevKitC-1-N8R8.

MicroPython Documentation

The MicroPython organization page

Download

MicroPython Firmware.bin file for Neuron modules

Download

Instructions for using Neurons with MicroPython

Download

3D Models and Printable Files

BrainBoardz utilizes a number of 3D printed parts in the mPCIe modules. These parts include the mPCIe riser, BrainBoardz board standoffs and OLED display supports. Our boards are provided with a complete set of parts. If you have access to an FDM printer you can also print replacement parts from the STL model files provided below. For the best results we recommend printing STL files with the following settings:

.2 mm Layer Height
3 perimeters (shells)
5 solid layers top
5 solid layers bottom
20% Infill
30 mm/s for perimeters (slow!)
50 mm/s for infill
Support Material is Not Required
PLA recommended

We do not recommend using FDM 3D printed nuts or bolts for attaching Neuron mPCIe module to a BrainBoardz. Instead we recommend M3 8mm nylon screws with either a metal or nylon M3 nuts. An M3 screw and nut are provided with every Neuron; replacements screws/nuts are available from our store, Amazon, AliExpress and other suppliers.

3D Models and 3D Printable Parts

FreeCAD Models for the Mini PCIe Board Riser, Board Legs and the OLED Riser

Download

3D Print Files in the STL File Format. To use with your preferred Slicer

Download

Schematics

We have published our board designs and requirements as an open source project on GitHub. You are welcome to design your own board! We do not allow 3rd party boards to use our name or logo, but you can indicate “BrainBoardz Compatible” on your board if it is 100% compatible and it is manufactured using a lead free solder.  Please ensure that you follow our design guidelines very closely. The pin assignments have to be 100% compatible and connector placement is extremely critical.  Also, please ensure that our Neurons run properly (including the MicroSD card and Blink LED) on your board design. The schematics for the Neuron-Z3 and Neuron-M3 and all BrainBoardz boards is released under the Creative Commons Attribution Share-Alike license Version 4.0. The software and firmware for Neuron and BrainBoardz Project is released under the GPL V3 License.

Neuron-Z3/M3 Schematics

Neuron Complete Schematics
(Including Gerber Files). We are publishing all design files on GitHub

Download
