NUCLEUS

Version: 5.3
Mounting Points
2X24 Pin Headers
mPCIe Connector
Board Dimensions: ~ 45mm W X 70mm H

Our most compact board for the Neuron M3/Z3.
The Nucleus is ideal for projects where mounting space is limited.

CORTEX

Version: 5.3
Mounting Points
2 X 24 Pin Headers
3V and 5V Pads
mPCIe Connector
Board Dimensions: ~ 64mm W X 73mm H

Our standard wide-layout board for the Neuron M3/Z3.
We have kept the Cortex as simple and inexpensive as possible.

SYNAPSE

Version: 5.3
2 Touch Sensors
Mounting Points
2 X 24 Pin Headers
3V and 5V Pads
mPCIe Connector
Board Dimensions: ~ 64mm W X 73mm H

Our standard board for the Neuron M3/Z3.
We have kept the Synapse as simple and inexpensive as possible.

PROTOBOARD MICRO

Version 5.3
2 Touch Sensors
2 X 24  Pin (Dual Row) Headers
Dedicated 2.54mm Power and Ground Header
Mounting Points
Mini Breadboard
mPCIe Connector
Board Dimensions: ~ 100mm W X 82mm H

The Protoboard Micro packs many of the core features
of the larger Protoboards in a very compact form factor.
It’s ideal for testing sensors and prototyping small projects.
We’ve included a variety of mounting options for the Micro.

PROTOBOARD MINI

Version: 5.3
2 Touch Sensors
3V and GND Pads
2 X 24 (Dual) Pin Headers
Dedicated 2.54mm Power and Ground Header
5V and Ground Pads
Mounting Points
Breadboard
mPCIe Connector
Board Dimensions: ~ 145mm W X 91mm H

The Protoboard Mini is perfect for larger projects.
The Mini packs all of the core features of the Protoboard
in a very compact form factor.

PROTOBOARD

Version: 5.13
2 Touch Sensors
5V DC Terminal Screw Connector
3V and GND Pads
4 X 24 Pin (Dual GPIO) Headers
Dedicated 2.54mm Power and Ground Header
Mounting Points
 Full Size Breadboard
mPCIe Connector
Board Dimensions: ~ 218mm W X 86mm H

The Protoboard is our large format breadboard system.
It is ideal for prototyping more complex projects.

NEXUS MINI

Version 5.3
5V DC Terminal Screw Connector
8 X 6 Pin 2.54mm Screw Terminal Headers
6P 2.54mm Power Header
Mounting Points
mPCIe Connector
Board Dimensions: ~ 69mm W X 66mm H

The Nexus Mini is ideal for projects that requires wiring
(rockets, micro-servos, AV/Alarm automation etc.).
The Mini  provides 8 screw terminals with 2.54mm spacing.
Additional power and ground from a dedicated header
We have also include a 5V adapter for external power.

NEXUS T-REX

Version 5.3
1 X 24P 2.54mm Headers
3 X 6 Pin 3.5mm Screw Terminal Headers
Mounting Points
mPCIe Connector
Board Dimensions: ~ 67mm W X 82mm H

The Nexus T-Rex is perfect for any project that requires
some wiring (rockets, micro-servo projects, AV
automation etc.) and some pins. You can power the T-REX
with a 5V source via a screw terminal connection.
The T-REX  provides 3 X 6 pin screw terminals with 3.5mm spacing.
