Our most recent Neuron-M and Neuron-P models are equipped with Espressif’s latest current generation ESP32-S3 Wroom-1 modules, providing a copious 8MB of Flash and 8MB of Octal PSRAM. Neurons are specifically designed for use in prototyping and board design. To provide the maximum degree of flexibility at the lowest possible price we have eliminated non-essential components wherever we can.

The components we have included are those that are most likely to be needed in core operations for the vast majority of prototypes and production. These include a ultra-low noise 5V to 3.3V LDO, a USB-C connector, a status LED and a MicroSD card reader. This razor focused approach ensures that we can provide the most affordable and flexible solution for your ESP32-S3 microcontroller based projects!

NEURON-M

ESP32-S3-WROOM-1 (Dual Core – 240 MHz)
8MB FLASH + 8MB OCTAL PSRAM
Wi-Fi + Bluetooth 5 (LE)
Micro SD Card Reader
Temperature Sensor
Status LED
Reset and Program Buttons
USB-C Connector
mPCIe Connector
Made in Canada with Lead Free Solder
Compatible with All BrainBoardz
Compatible with ESP-IDF, Arduino, CircuitPython
MicroPython and PlatformIO

Neuron-M and Neuron-P Pinout (PDF) Document

NEURON-P

ESP32-S3 WROOM-1 (Dual Core – 240 MHz)
8MB FLASH + 8MB OCTAL PSRAM
Wi-Fi + Bluetooth 5 (LE)
Micro SD Card Reader
Temperature Sensor
Status LED
Reset and Program Buttons
USB-C Connector
2 X 20 pin 2.54mm Headers
1 X 2 pin 2.54mm 3V+Ground Header
1 X 2 pin 2.54mm 5V+Ground Header
Pin 46 + Pin 3 2.54mm Header
Made in Canada with Lead Free Solder
Compatible with ESP-IDF, Arduino, CircuitPython
MicroPython and PlatformIO

Neuron-M and Neuron-P Pinout (PDF) Document
